| Design Speed | 200 m/min |
| Production Speed | 180 - 200 m/min (Stable) |
| Working Width | 1750 mm - 2850 mm (Customizable) |
| Jumbo Roll Dia. | ≤ Φ2500 mm (Standard) |
| Finished Log Dia. | Φ70 - Φ135 mm |
| Perforation System | 4-Blade Spiral Knife (High Precision) |
| Rewinding Type | Non-Stop (Core & Coreless Ready) |
| Control System | PLC, Inverter, Optical-Electro-Mechanical Integration |
| Embossing Unit | Edge Embossing (Standard) / Lamination (Optional) |
| Sealing Speed | 20 Logs/Min |
| Sealing Type | Glue-Free Technology (Water/Pressure) |
| Consumables | Zero Cost (No Glue Required) |
| Operation | Fully Automatic (Servo Controlled) |
| Power Consumption | 7.12 KW (Energy Efficient) |
| Backstand Capacity | 1 - 3 Ply (Customizable Configuration) |
| Driving Mode | Independent Motor Drive (Per Stand) |
| Parent Roll Dia. | ≤ Φ2500 mm (Standard) |
| Parent Roll Width | 1750 mm - 2850 mm |
| Core Diameter | 3" (76.2 mm) Standard |
| Tension Control | Automatic Constant Tension System |
| Paper Loading | Pneumatic Lifting System |
| Printing Unit | 1 - 2 Colors (Optional Add-On) |
Technical experts ready to respond within 24 business hours
Yes. The TB-R200 is equipped with a patented vacuum suction technology specifically designed for Coreless Rewinding. This allows you to switch between standard cored rolls and solid coreless rolls, giving you market versatility without buying two machines.
The integrated Glue-Free Sealer uses advanced water or pressure sealing instead of traditional glue. This significantly reduces your operational costs (no consumables), eliminates maintenance downtime caused by glue residue, and creates a more eco-friendly final product.
Not at all. We have designed the TB-R200 with a user-friendly large-screen HMI (Touchscreen). The system includes automatic web break detection and remote terminal connection, allowing our engineers to assist you with diagnostics remotely if needed.
This line is designed with a compact footprint, making it ideal for facilities with limited space. It operates on a standard 3-Phase power supply (Customizable to your region). Detailed layout drawings will be provided by our engineering team upon inquiry.
