Heavy-duty automated extraction system designed to handle massive Jumbo Roll spools up to 3000kg, eliminating manual labor and preventing operator injury during changeovers.
The TB-MOD eliminates the most dangerous manual task in production: handling heavy Jumbo Roll spools. Engineered with a reinforced steel structure and high-torque drive, it extracts spools up to 3000kg with absolute precision, preventing operator injury and reducing changeover downtime by up to 50%.
Designed to manage massive loads effortlessly. The reinforced steel carriage supports Jumbo Roll Spools up to 3000kg without deflection, ensuring safe and stable extraction even under maximum weight conditions.
Eliminates manual positioning errors. The motorized vertical column and laser-guided alignment system sync perfectly with the rewinder core height, preventing damage to expensive expander shafts during extraction.
Engineered for absolute stability. The heavy-duty industrial chain drive system and hydraulic cylinders ensure smooth, vibration-free vertical adjustment, guaranteeing exact alignment with the unwinder core height every time.
| Max. Spool Length | Up to 4000mm (Customizable) |
| Max. Pulling Force | 3000 kg |
| Pulling Speed | 10 - 20 m/min (High Torque) |
| Lifting Stroke | Hydraulic / Motorized Adjustment |
| Drive System | Heavy-Duty AC Motor + Chain Drive |
| Control System | Standalone PLC Console |
| Total Power | 5.5 kW |
| Air Pressure | 6 - 8 Bar |
Get a Technical Proposal & Layout within 24h.
