Log Saw / Band Saw
TB-JRT100 Orbital Log Saw
Heavy-duty orbital cutting system for JRT/Maxi Rolls. Delivers 100 cuts/min with a mirror-smooth finish and auto-sharpening, handling diameters up to 300mm.
View Details
| Design Speed | 250 m/min |
| Production Speed | 200 m/min (Stable) |
| Raw Paper Width | 1750 mm - 2850 mm (Customizable) |
| Raw Paper Diameter | Φ1500-2500 mm (Customizable) |
| Finished Log Diameter | Φ80 - Φ150 mm |
| Perforation System | 4 Helical Blades (High Precision) |
| Rewinding Type | Non-stop |
| Control System | PLC, Inverters, Mechatronic Integration |
| Lamination Function | Glue Lamination System (Optional) |
| Printing Unit | 1 - 2 Colors (Optional Plugin) |
| Sealing Speed | 12-20 logs/min |
| Sealing Type | Glueless Technology (Water/Pressure Seal) |
| Consumables | Zero Cost (No Glue Required) |
| Operation Mode | Fully Automatic (Servo Control) |
| Power Consumption | 8 KW (Energy Saving) |
| Unwind Stand Layers | 1 - 5 Layers (Customizable Configuration) |
| Drive Mode | Independent Motor Drive (Single Stand) |
| Parent Roll Diameter | Φ1500-2500 mm (Customizable) |
| Parent Roll Width | 1750 mm - 2850 mm (Customizable) |
| Core Diameter | 3-10 inches |
| Loading Method | Pneumatic Lift System |
Technical experts ready to respond within 24 business hours
Yes. The TB-R200 is equipped with a patented vacuum suction technology specifically designed for Coreless Rewinding. This allows you to switch between standard cored rolls and solid coreless rolls, giving you market versatility without buying two machines.
The integrated Glue-Free Sealer uses advanced water or pressure sealing instead of traditional glue. This significantly reduces your operational costs (no consumables), eliminates maintenance downtime caused by glue residue, and creates a more eco-friendly final product.
Not at all. We have designed the TB-R200 with a user-friendly large-screen HMI (Touchscreen). The system includes automatic web break detection and remote terminal connection, allowing our engineers to assist you with diagnostics remotely if needed.
This line is designed with a compact footprint, making it ideal for facilities with limited space. It operates on a standard 3-Phase power supply (Customizable to your region). Detailed layout drawings will be provided by our engineering team upon inquiry.
